09-65-2039
Molex
Molex
3CKT 3.96MM WFAS W/LOCK 52
$0.25
Available to order
Reference Price (USD)
1+
$0.25100
500+
$0.24849
1000+
$0.24598
1500+
$0.24347
2000+
$0.24096
2500+
$0.23845
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The 09-65-2039 by Molex is a versatile rectangular connector header designed for male pin connections. With a focus on quality and precision, these headers support various PCB layouts and configurations. Ideal for applications in robotics, power supplies, and audio equipment. Molex delivers connectors that meet the needs of modern electronics with unmatched reliability.
Specifications
- Product Status: Active
- Connector Type: Header
- Contact Type: Male Pin
- Pitch - Mating: 0.156" (3.96mm)
- Number of Positions: 3
- Number of Rows: 1
- Row Spacing - Mating: -
- Number of Positions Loaded: All
- Style: Board to Cable/Wire
- Shrouding: Shrouded - 1 Wall
- Mounting Type: Through Hole
- Termination: Solder
- Fastening Type: Friction Lock
- Contact Length - Mating: 0.419" (10.65mm)
- Contact Length - Post: 0.143" (3.63mm)
- Overall Contact Length: 0.687" (17.45mm)
- Insulation Height: 0.482" (12.25mm)
- Contact Shape: Square
- Contact Finish - Mating: Tin
- Contact Finish Thickness - Mating: -
- Contact Finish - Post: Tin
- Contact Material: Brass
- Insulation Material: Polyamide (PA66), Nylon 6/6
- Features: -
- Operating Temperature: -
- Ingress Protection: -
- Material Flammability Rating: UL94 V-2
- Insulation Color: -
- Current Rating (Amps): -
- Voltage Rating: -
