12226-1100-00 FR
3M
3M
SHRUNK DELTA RIBBON CONN 26 CONT
$10.01
Available to order
Reference Price (USD)
1+
$8.37000
10+
$8.02200
25+
$7.32480
50+
$6.97600
100+
$6.62720
250+
$5.92960
500+
$5.58080
1,000+
$4.88320
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The 12226-1100-00 FR series from 3M sets new benchmarks for D-Shaped Connectors - Centronics types in the Connectors and Interconnects marketplace. Featuring advanced contact physics and ergonomic designs, these connectors provide exceptional mating cycle durability (exceeding 5,000 cycles) and low insertion force requirements. Notable technical specifications include 1.27mm contact spacing, tin or gold plating options, and UL94V-0 flame-rated housing materials. These components find extensive use in medical imaging equipment, industrial barcode scanners, and laboratory instrumentation. For instance, they're frequently specified for MRI machine peripherals and automated warehouse tracking systems requiring robust parallel data interfaces.
Specifications
- Product Status: Active
- Connector Style: Outer Shroud Contacts
- Connector Type: Receptacle
- Number of Positions: 26
- Number of Rows: 2
- Mounting Type: Panel Mount, Through Hole
- Termination: Solder
- Flange Feature: Housing/Shell (Unthreaded)
- Type: -
- Features: Board Lock, Shielded
- Contact Finish: Gold
- Contact Finish Thickness: 30.0µin (0.76µm)
