1N3309R
Solid State Inc.
Solid State Inc.
DO5 50 WATT ZENER DIODES
$8.50
Available to order
Reference Price (USD)
1+
$8.50000
500+
$8.415
1000+
$8.33
1500+
$8.245
2000+
$8.16
2500+
$8.075
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Meet the 1N3309R Zener diode from Solid State Inc., a standout in the Discrete Semiconductor Products category. This single Zener diode is designed for high-performance voltage regulation, with features like sharp breakdown voltage and minimal power dissipation. It is widely used in consumer electronics, such as gaming consoles and smart home devices, to ensure stable operation. The 1N3309R is also integral to automotive systems, where it safeguards electronic components from voltage fluctuations. Additionally, it finds applications in medical equipment, providing reliable voltage references for diagnostic devices and patient monitors.
Specifications
- Product Status: Active
- Voltage - Zener (Nom) (Vz): 10 V
- Tolerance: ±20%
- Power - Max: 50 W
- Impedance (Max) (Zzt): 0.6 Ohms
- Current - Reverse Leakage @ Vr: -
- Voltage - Forward (Vf) (Max) @ If: 1.5 V @ 10 A
- Operating Temperature: -65°C ~ 175°C (TJ)
- Mounting Type: Stud Mount
- Package / Case: DO-203AB, DO-5, Stud
- Supplier Device Package: DO-5
