1N5756D
Microchip Technology
Microchip Technology
DIODE ZENER 68V 500MW DO35
$4.50
Available to order
Reference Price (USD)
202+
$5.08401
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The 1N5756D by Microchip Technology is a high-performance single Zener diode, part of the Discrete Semiconductor Products lineup. Designed for accuracy and reliability, this diode features low dynamic impedance and excellent temperature stability. It is widely used in voltage reference circuits, power supplies, and signal conditioning applications. For instance, the 1N5756D is essential in medical imaging devices, where it maintains precise voltage levels for accurate diagnostics. It also plays a critical role in aerospace electronics, ensuring reliable operation under extreme conditions. Furthermore, it is used in consumer electronics, such as smart TVs and home appliances, to enhance performance and longevity.
Specifications
- Product Status: Active
- Voltage - Zener (Nom) (Vz): 68 V
- Tolerance: ±1%
- Power - Max: 500 mW
- Impedance (Max) (Zzt): 240 Ohms
- Current - Reverse Leakage @ Vr: 100 nA @ 48 V
- Voltage - Forward (Vf) (Max) @ If: 900 mV @ 10 mA
- Operating Temperature: -65°C ~ 175°C
- Mounting Type: Through Hole
- Package / Case: DO-204AH, DO-35, Axial
- Supplier Device Package: DO-35
