1SMA5956H
Taiwan Semiconductor Corporation
Taiwan Semiconductor Corporation
DIODE ZENER 200V 1.5W DO214AC
$0.11
Available to order
Reference Price (USD)
1+
$0.10622
500+
$0.1051578
1000+
$0.1040956
1500+
$0.1030334
2000+
$0.1019712
2500+
$0.100909
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Engineered for excellence, the 1SMA5956H Zener diode from Taiwan Semiconductor Corporation is a critical component in the Discrete Semiconductor Products category. This single Zener diode is designed to deliver unmatched voltage regulation, with features such as high surge current capability and low dynamic impedance. It is particularly suited for applications in automotive electronics, where it protects ECUs and sensors from voltage surges. The 1SMA5956H is also widely used in industrial automation, providing stable voltage references for PLCs and motor drives. Its versatility extends to consumer electronics, where it ensures the longevity of devices like smartphones and laptops by preventing voltage overloads.
Specifications
- Product Status: Active
- Voltage - Zener (Nom) (Vz): 200 V
- Tolerance: ±5%
- Power - Max: 1.5 W
- Impedance (Max) (Zzt): 1.2 kOhms
- Current - Reverse Leakage @ Vr: 500 nA @ 152 V
- Voltage - Forward (Vf) (Max) @ If: -
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: DO-214AC, SMA
- Supplier Device Package: DO-214AC (SMA)
