2041-2X11G10SA-A003
Oupiin
Oupiin
PCB SOCKET, DOUBLE ROW, 22 PIN,
$1.77
Available to order
Reference Price (USD)
1+
$1.77000
500+
$1.7523
1000+
$1.7346
1500+
$1.7169
2000+
$1.6992
2500+
$1.6815
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The 2041-2X11G10SA-A003 Oupiin Rectangular Connectors - Headers, Receptacles, and Female Sockets offer superior connectivity solutions for modern electronics. Designed with versatility in mind, these connectors support high-speed data transfer and power delivery. Their compact design and rugged build make them suitable for aerospace, military, and IoT applications. Whether you need board-to-board, cable-to-board, or wire-to-wire connections, Oupiin provides reliable options. Examples include avionics systems, defense equipment, and smart home devices.
Specifications
- Product Status: Active
- Connector Type: Socket
- Contact Type: Female Socket
- Style: Board to Board
- Number of Positions: 22
- Number of Positions Loaded: 20
- Pitch - Mating: 0.100" (2.54mm)
- Number of Rows: 2
- Row Spacing - Mating: 0.100" (2.54mm)
- Mounting Type: Through Hole
- Termination: Solder
- Fastening Type: Push-Pull
- Contact Finish - Mating: Gold
- Contact Finish Thickness - Mating: 10.0µin (0.25µm)
- Insulation Color: -
- Insulation Height: 0.197" (5.00mm)
- Contact Length - Post: 0.126" (3.20mm)
- Operating Temperature: -55°C ~ 105°C
- Material Flammability Rating: UL94 V-0
- Contact Finish - Post: Gold
- Mated Stacking Heights: -
- Ingress Protection: -
- Features: -
- Current Rating (Amps): 2A
- Voltage Rating: -
