2N5060G
onsemi
onsemi
SCR 30V 800MA TO92-3
$0.00
Available to order
Reference Price (USD)
1+
$0.00000
500+
$0
1000+
$0
1500+
$0
2000+
$0
2500+
$0
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The 2N5060G from onsemi redefines reliability in the Thyristors - SCRs category of Discrete Semiconductor Products. With its unique reverse blocking capability and high temperature operation range, this SCR is indispensable for power electronics. Typical uses include uninterruptible power supplies, induction heating, and plasma cutting machines. For example, it's essential in semiconductor manufacturing equipment. onsemi's 2N5060G combines advanced engineering with practical functionality.
Specifications
- Product Status: Obsolete
- Voltage - Off State: 30 V
- Voltage - Gate Trigger (Vgt) (Max): 800 mV
- Current - Gate Trigger (Igt) (Max): 200 µA
- Voltage - On State (Vtm) (Max): 1.7 V
- Current - On State (It (AV)) (Max): 510 mA
- Current - On State (It (RMS)) (Max): 800 mA
- Current - Hold (Ih) (Max): 5 mA
- Current - Off State (Max): 10 µA
- Current - Non Rep. Surge 50, 60Hz (Itsm): 10A @ 60Hz
- SCR Type: Sensitive Gate
- Operating Temperature: -40°C ~ 110°C
- Mounting Type: Through Hole
- Package / Case: TO-226-3, TO-92-3 Long Body
- Supplier Device Package: TO-92 (TO-226)
