628-24W7224-1TB
EDAC Inc.
EDAC Inc.
CONN D-SUB RCPT 24POS VERT SLDR
$13.54
Available to order
Reference Price (USD)
1+
$13.54500
500+
$13.40955
1000+
$13.2741
1500+
$13.13865
2000+
$13.0032
2500+
$12.86775
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Upgrade your connectivity solutions with EDAC Inc.'s 628-24W7224-1TB D-Sub connectors - the industry standard for robust interconnections. These connectors in our Interconnects category feature gold-plated contacts for optimal conductivity and corrosion resistance. The 628-24W7224-1TB series includes both standard and high-density configurations suitable for military, aerospace, and transportation applications. Engineers trust these D-Subs for avionics systems, railway signaling equipment, and naval electronics due to their MIL-DTL-24308 compliance. Each connector undergoes rigorous testing for insertion durability (500+ cycles) and environmental resistance, making them ideal for harsh operating conditions.
Specifications
- Product Status: Active
- Connector Style: D-Sub, Combo
- Connector Type: Receptacle, Female Sockets
- Number of Positions: 24 (17 + 7 Power)
- Number of Rows: 2
- Mounting Type: Through Hole
- Shell Size, Connector Layout: 5 (DD, D) - 24W7
- Contact Type: Signal and Power
- Flange Feature: Board Side (M3)
- Termination: Solder
- Primary Material: -
- Shell Material, Finish: Steel, Tin Plated
- Contact Finish: Gold
- Contact Finish Thickness: Flash
- Ingress Protection: -
- Material Flammability Rating: UL94 V-0
- Current Rating (Amps): 5A, 10A
- Backset Spacing: -
- Features: Shielded
