628-M09-623-WT6
EDAC Inc.
EDAC Inc.
CONN D-SUB RCPT 9POS VERT SLDR
$12.24
Available to order
Reference Price (USD)
1+
$12.23780
500+
$12.115422
1000+
$11.993044
1500+
$11.870666
2000+
$11.748288
2500+
$11.62591
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The 628-M09-623-WT6 D-Sub series by EDAC Inc. sets new benchmarks in the Connectors and Interconnects category. These high-density connectors pack up to 104 contacts in compact DA-26 shells while maintaining 500VAC isolation. Key applications include flight data recorders, nuclear power plant controls, and underground mining equipment where space efficiency and reliability are critical. The 628-M09-623-WT6 differentiates itself with integrated grounding lugs, removable contact modules, and optional potting for environmental sealing. Electrical engineers value these connectors for their low insertion force design and compatibility with automated assembly processes.
Specifications
- Product Status: Active
- Connector Style: D-Sub
- Connector Type: Receptacle, Female Sockets
- Number of Positions: 9
- Number of Rows: 2
- Mounting Type: Through Hole
- Shell Size, Connector Layout: 1 (DE, E)
- Contact Type: Signal and Power
- Flange Feature: Mating Side (4-40)
- Termination: Solder
- Primary Material: -
- Shell Material, Finish: Steel, Tin Plated
- Contact Finish: Gold
- Contact Finish Thickness: 30.0µin (0.76µm)
- Ingress Protection: -
- Material Flammability Rating: UL94 V-0
- Current Rating (Amps): 5A per Contact
- Backset Spacing: -
- Features: Board Lock, Shielded
