629-25W3640-5TB
EDAC Inc.

EDAC Inc.
CONN D-SUB PLUG 25POS R/A SLDR
$22.23
Available to order
Reference Price (USD)
1+
$22.22909
500+
$22.0067991
1000+
$21.7845082
1500+
$21.5622173
2000+
$21.3399264
2500+
$21.1176355
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Optimize your interconnect strategy with EDAC Inc.'s innovative 629-25W3640-5TB D-Sub connector solutions. Our catalog highlights these connectors' space-saving stacked configurations and right-angle PCB mounting options. The 629-25W3640-5TB shines in laboratory automation, packaging machinery, and textile manufacturing equipment where high-cycle durability is required. Specialized versions include filtered models for sensitive instrumentation and high-voltage variants for power distribution systems. These connectors support mixed signal transmission (analog+digital+power) with crosstalk reduction technology, making them perfect for factory automation networks and process control systems.
Specifications
- Product Status: Active
- Connector Style: D-Sub, Combo
- Connector Type: Plug, Male Pins
- Number of Positions: 25 (22 + 3 Coax)
- Number of Rows: 2
- Mounting Type: Through Hole, Right Angle
- Shell Size, Connector Layout: 4 (DC, C) - 25W3
- Contact Type: Coax and Signal
- Flange Feature: Housing/Shell (M3)
- Termination: Solder
- Primary Material: -
- Shell Material, Finish: Steel, Tin Plated
- Contact Finish: Gold
- Contact Finish Thickness: 30.0µin (0.76µm)
- Ingress Protection: -
- Material Flammability Rating: UL94 V-0
- Current Rating (Amps): -
- Backset Spacing: 0.370" (9.40mm)
- Features: Board Lock, Grounding Indents, Mounting Brackets
