802-10-072-30-001101

Preci-Dip

Manufacturer

Preci-Dip

Description:

CONN HEADER SMD 72POS 2.54MM

Datasheet:

802-10-072-30-001101 Datasheet

$12.32

Available to order

Reference Price (USD)

$9.01000

10+

$8.62000

100+

$7.24850

500+

$6.07304

1,000+

$5.36778

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

The 802-10-072-30-001101 from Preci-Dip is a high-quality rectangular connector header designed for reliable interconnections in various electronic applications. These male pin headers feature a robust construction, ensuring secure and stable connections. Ideal for PCB mounting, the 802-10-072-30-001101 offers excellent electrical performance and durability. With options for different pin counts and pitches, this connector is versatile for numerous industrial and consumer electronics. Applications include automotive systems, telecommunications equipment, and home appliances. Choose Preci-Dip for precision-engineered connectors that meet global standards.

Specifications

Product Status: Active
Connector Type: Header
Contact Type: Male Pin
Pitch - Mating: 0.100" (2.54mm)
Number of Positions: 72
Number of Rows: 2
Row Spacing - Mating: 0.100" (2.54mm)
Number of Positions Loaded: All
Style: Board to Board
Shrouding: Unshrouded
Mounting Type: Surface Mount
Termination: Solder
Fastening Type: Push-Pull
Contact Length - Mating: 0.191" (4.85mm)
Contact Length - Post: -
Overall Contact Length: -
Insulation Height: 0.110" (2.79mm)
Contact Shape: Circular
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 10.0µin (0.25µm)
Contact Finish - Post: Gold
Contact Material: Brass
Insulation Material: Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Features: -
Operating Temperature: -55°C ~ 125°C
Ingress Protection: -
Material Flammability Rating: UL94 V-0
Insulation Color: Black
Current Rating (Amps): 3A
Voltage Rating: 150VDC
