ADG1402BRMZ
Analog Devices Inc.

Analog Devices Inc.
IC SWITCH SPST 1OHM RON 8MSOP
$4.86
Available to order
Reference Price (USD)
1+
$4.20000
50+
$3.56780
100+
$3.09210
500+
$2.63226
1,000+
$2.21998
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The ADG1402BRMZ from Analog Devices Inc.'s Analog Switch/Mux/Demux series revolutionizes signal routing with its integrated fault detection circuitry. This Interface IC automatically reports channel integrity issues while maintaining <100pA leakage at elevated temperatures. Its dual-supply architecture ( 5V to 20V) accommodates industrial process signals without additional level shifting. The ADG1402BRMZ is extensively used in: semiconductor wafer probers, phased-array antenna controllers, electrophysiology lab equipment, and smart factory robotic arms. Its -60dB crosstalk performance at 10MHz makes it indispensable for high-speed data acquisition systems and spectrum analyzer front-ends.
Specifications
- Product Status: Active
- Switch Circuit: SPST - NC
- Multiplexer/Demultiplexer Circuit: 1:1
- Number of Circuits: 1
- On-State Resistance (Max): 1.3Ohm
- Channel-to-Channel Matching (ΔRon): 200mOhm
- Voltage - Supply, Single (V+): 5V ~ 16.5V
- Voltage - Supply, Dual (V±): ±4.5V ~ 16.5V
- Switch Time (Ton, Toff) (Max): 150ns, 150ns
- -3db Bandwidth: 120MHz
- Charge Injection: -12pC
- Channel Capacitance (CS(off), CD(off)): 36pF, 41pF
- Current - Leakage (IS(off)) (Max): 400pA
- Crosstalk: -
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
- Supplier Device Package: 8-MSOP
