ADP7158ACPZ-3.3-R7

Analog Devices Inc.

Manufacturer

Analog Devices Inc.

Description:

IC REG LINEAR 3.3V 2A 10LFCSP

Datasheet:

ADP7158ACPZ-3.3-R7 Datasheet

$9.64

Available to order

Reference Price (USD)

1,500+

$4.33593

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

Analog Devices Inc.'s ADP7158ACPZ-3.3-R7 represents the cutting edge in linear voltage regulator technology within our Integrated Circuits (ICs) inventory. This PMIC component delivers fixed or adjustable output voltages with outstanding line and load regulation performance. The device incorporates advanced protection features including over-temperature and short-circuit protection, making it exceptionally reliable for critical applications. Linear voltage regulators like the ADP7158ACPZ-3.3-R7 are fundamental in automotive electronics (for infotainment systems and ECUs), industrial control systems, and telecommunications infrastructure where voltage stability is paramount. Engineers particularly value these ICs for their simplicity of design and minimal external component requirements.

Specifications

Product Status: Active
Output Configuration: Positive
Output Type: Fixed
Number of Regulators: 1
Voltage - Input (Max): 5.5V
Voltage - Output (Min/Fixed): 3.3V
Voltage - Output (Max): -
Voltage Dropout (Max): 0.28V @ 2A
Current - Output: 2A
Current - Quiescent (Iq): 8 mA
Current - Supply (Max): 14 mA
PSRR: 70dB ~ 50dB (1kHz ~ 1MHz)
Control Features: Enable
Protection Features: Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Operating Temperature: -40°C ~ 125°C
Mounting Type: Surface Mount
Package / Case: 10-VFDFN Exposed Pad, CSP
Supplier Device Package: 10-LFCSP-WD (3x3)
