ATP04-2P-BM12
Amphenol Sine Systems Corp
Amphenol Sine Systems Corp
2 POSITION, STRAIGHT PCB RECEPTA
$7.59
Available to order
Reference Price (USD)
1+
$7.59000
500+
$7.5141
1000+
$7.4382
1500+
$7.3623
2000+
$7.2864
2500+
$7.2105
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The ATP04-2P-BM12 by Amphenol Sine Systems Corp is a premium rectangular connector header designed for male pin connections. Engineered for precision, these headers offer low insertion loss and high mating cycles. Perfect for high-density PCB applications, the ATP04-2P-BM12 supports various configurations to meet diverse needs. Its applications span across data communication, military equipment, and renewable energy systems. Amphenol Sine Systems Corp ensures each connector meets rigorous quality standards for global compliance.
Specifications
- Product Status: Active
- Connector Type: Receptacle
- Contact Type: Male Pin
- Pitch - Mating: 0.264" (6.70mm)
- Number of Positions: 2
- Number of Rows: 1
- Row Spacing - Mating: -
- Number of Positions Loaded: All
- Style: Board to Cable/Wire
- Shrouding: Shrouded - 4 Wall
- Mounting Type: Through Hole
- Termination: Solder
- Fastening Type: Latch Holder
- Contact Length - Mating: -
- Contact Length - Post: 0.146" (3.70mm)
- Overall Contact Length: -
- Insulation Height: 1.126" (28.60mm)
- Contact Shape: Circular
- Contact Finish - Mating: Gold
- Contact Finish Thickness - Mating: -
- Contact Finish - Post: Gold
- Contact Material: Copper Alloy
- Insulation Material: Thermoplastic
- Features: Board Guide, Potting Wall, Sealed
- Operating Temperature: -55°C ~ 125°C
- Ingress Protection: IP68/IP69K - Dust Tight, Water Resistant, Waterproof
- Material Flammability Rating: -
- Insulation Color: Black
- Current Rating (Amps): 25A
- Voltage Rating: -
