BAT54C-TP
Micro Commercial Co
Micro Commercial Co
DIODE ARRAY SCHOTTKY 30V SOT23
$0.29
Available to order
Reference Price (USD)
3,000+
$0.05100
6,000+
$0.04500
15,000+
$0.03900
30,000+
$0.03700
75,000+
$0.03500
150,000+
$0.03300
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The BAT54C-TP rectifier array from Micro Commercial Co redefines efficiency in the Diodes - Rectifiers - Arrays classification. Its optimized chip geometry enables higher surge withstand capability, critical for automotive alternators and arc suppression circuits. This product shines in three-phase rectification and snubber networks, offering aerospace-grade reliability. Micro Commercial Co's precision manufacturing ensures each BAT54C-TP meets stringent quality standards for mission-critical applications.
Specifications
- Product Status: Active
- Diode Configuration: 1 Pair Common Cathode
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 30 V
- Current - Average Rectified (Io) (per Diode): 200mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 1 V @ 100 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr): 5 ns
- Current - Reverse Leakage @ Vr: 2 µA @ 25 V
- Operating Temperature - Junction: -55°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: SOT-23
