BAT54CWFILMY
STMicroelectronics
STMicroelectronics
DIODE ARRAY SCHOTTKY 40V SOT323
$0.53
Available to order
Reference Price (USD)
3,000+
$0.09751
6,000+
$0.09261
15,000+
$0.08526
30,000+
$0.08036
75,000+
$0.07791
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Introducing STMicroelectronics's BAT54CWFILMY, a game-changing diode array in the Discrete Semiconductor Products category. Specifically engineered for high-frequency rectification, this component minimizes switching losses in SMPS and RF circuits. Its hermetically sealed package provides exceptional moisture resistance for outdoor applications like traffic signal systems and railway electronics. Trust STMicroelectronics's decades of semiconductor expertise embedded in every BAT54CWFILMY for uncompromising performance.
Specifications
- Product Status: Active
- Diode Configuration: 1 Pair Common Cathode
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 40 V
- Current - Average Rectified (Io) (per Diode): 300mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 900 mV @ 100 mA
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 5 ns
- Current - Reverse Leakage @ Vr: 1 µA @ 30 V
- Operating Temperature - Junction: -40°C ~ 150°C
- Mounting Type: Surface Mount
- Package / Case: SC-70, SOT-323
- Supplier Device Package: SOT-323
