BAT54CWT1G
onsemi
onsemi
DIODE ARRAY SCHOTTKY 30V SOT323
$0.22
Available to order
Reference Price (USD)
3,000+
$0.03920
6,000+
$0.03428
15,000+
$0.02936
30,000+
$0.02772
75,000+
$0.02608
150,000+
$0.02444
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The BAT54CWT1G rectifier array from onsemi redefines efficiency in the Diodes - Rectifiers - Arrays classification. Its optimized chip geometry enables higher surge withstand capability, critical for automotive alternators and arc suppression circuits. This product shines in three-phase rectification and snubber networks, offering aerospace-grade reliability. onsemi's precision manufacturing ensures each BAT54CWT1G meets stringent quality standards for mission-critical applications.
Specifications
- Product Status: Active
- Diode Configuration: 1 Pair Common Cathode
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 30 V
- Current - Average Rectified (Io) (per Diode): 200mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 800 mV @ 100 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr): 5 ns
- Current - Reverse Leakage @ Vr: 2 µA @ 25 V
- Operating Temperature - Junction: -55°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: SC-70, SOT-323
- Supplier Device Package: SC-70-3 (SOT323)
