BAT54S-AQ
Diotec Semiconductor
Diotec Semiconductor
SCHOTTKY SOT-23 30V 0.2A
$0.04
Available to order
Reference Price (USD)
1+
$0.03850
500+
$0.038115
1000+
$0.03773
1500+
$0.037345
2000+
$0.03696
2500+
$0.036575
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover the high-performance BAT54S-AQ from Diotec Semiconductor, a premium diode rectifier array designed for efficient power conversion in demanding applications. As part of the Discrete Semiconductor Products category, this diode array ensures reliable rectification with low forward voltage drop and high surge current capability. Ideal for power supplies, motor controls, and inverters, the BAT54S-AQ delivers exceptional durability and thermal performance. Whether you're designing industrial equipment or automotive electronics, trust Diotec Semiconductor's cutting-edge technology for superior efficiency and longevity.
Specifications
- Product Status: Active
- Diode Configuration: 1 Pair Series Connection
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 30 V
- Current - Average Rectified (Io) (per Diode): 200mA
- Voltage - Forward (Vf) (Max) @ If: 1 V @ 100 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr): 5 ns
- Current - Reverse Leakage @ Vr: 2 µA @ 25 V
- Operating Temperature - Junction: -55°C ~ 150°C
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: SOT-23-3 (TO-236)
