BAT54SDW-7-F
Diodes Incorporated
Diodes Incorporated
DIODE ARRAY SCHOTTKY 30V SOT363
$0.51
Available to order
Reference Price (USD)
3,000+
$0.11000
6,000+
$0.10450
15,000+
$0.09625
30,000+
$0.09075
75,000+
$0.08800
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Engineered for excellence, Diodes Incorporated's BAT54SDW-7-F represents the next generation of rectifier diode arrays. This Discrete Semiconductor Product features innovative passivation layers that enhance reliability in humid conditions. Its primary applications include marine electronics, oil drilling equipment, and military power systems where corrosion resistance is paramount. With Diodes Incorporated's proprietary screening processes, the BAT54SDW-7-F guarantees exceptional performance in the most challenging electrical environments.
Specifications
- Product Status: Active
- Diode Configuration: 2 Pair Series Connection
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 30 V
- Current - Average Rectified (Io) (per Diode): 200mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 1 V @ 100 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr): 5 ns
- Current - Reverse Leakage @ Vr: 2 µA @ 25 V
- Operating Temperature - Junction: -65°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: 6-TSSOP, SC-88, SOT-363
- Supplier Device Package: SOT-363
