BAT54TQ-7-F
Diodes Incorporated
Diodes Incorporated
SCHOTTKY DIODE SOT523 T&R 3K
$0.10
Available to order
Reference Price (USD)
3,000+
$0.10000
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Optimize your electronic designs with the BAT54TQ-7-F single rectifier diode from Diodes Incorporated. This diode, part of the Discrete Semiconductor Products family, offers exceptional rectification efficiency and thermal stability. Its compact design and high current capacity make it suitable for space-constrained applications like mobile devices, laptops, and IoT gadgets. The BAT54TQ-7-F is also ideal for automotive electronics, including alternators and voltage regulators, where reliability is critical. Diodes Incorporated's commitment to innovation ensures that the BAT54TQ-7-F meets the highest industry standards for performance and longevity.
Specifications
- Product Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 30 V
- Current - Average Rectified (Io): 200mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 1 V @ 100 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr): -
- Current - Reverse Leakage @ Vr: 2 µA @ 25 V
- Capacitance @ Vr, F: 10pF @ 10V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: SOT-523
- Supplier Device Package: SOT-523
- Operating Temperature - Junction: -65°C ~ 150°C
