BAT760/6Z
Nexperia USA Inc.
Nexperia USA Inc.
DIODE SCHOTTKY 20V 1A SOD323
$0.00
Available to order
Reference Price (USD)
1+
$0.00000
500+
$0
1000+
$0
1500+
$0
2000+
$0
2500+
$0
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The BAT760/6Z single rectifier diode by Nexperia USA Inc. is a standout in the Diodes - Rectifiers - Single classification. Known for its robust construction and high rectification efficiency, it is perfect for demanding applications like electric vehicle charging stations and industrial robotics. Its low power dissipation and high thermal stability ensure optimal performance in data storage systems and server farms. The BAT760/6Z is also used in consumer gadgets, such as smartphones and tablets, highlighting its adaptability. Nexperia USA Inc.'s BAT760/6Z is the ultimate solution for high-performance rectification needs.
Specifications
- Product Status: Obsolete
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 20 V
- Current - Average Rectified (Io): 1A (DC)
- Voltage - Forward (Vf) (Max) @ If: 550 mV @ 1 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): -
- Current - Reverse Leakage @ Vr: 50 µA @ 15 V
- Capacitance @ Vr, F: 19pF @ 5V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: SC-76, SOD-323
- Supplier Device Package: SOD-323
- Operating Temperature - Junction: 125°C
