BAV199DWQ-7-F
Diodes Incorporated
Diodes Incorporated
DIODE ARRAY GP 85V 140MA SOT363
$0.44
Available to order
Reference Price (USD)
3,000+
$0.09500
6,000+
$0.09025
15,000+
$0.08313
30,000+
$0.07838
75,000+
$0.07600
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Power your designs with the BAV199DWQ-7-F diode rectifier array by Diodes Incorporated, a flagship product in the Diodes - Rectifiers - Arrays subcategory. Featuring dual-diode common cathode/anode configurations, this versatile component excels in voltage doubling circuits and flyback converters. Its lead-free construction meets global environmental standards while maintaining robust performance in appliance controls and HVAC systems. Diodes Incorporated delivers this industry-leading solution with full traceability and RoHS compliance.
Specifications
- Product Status: Active
- Diode Configuration: 2 Pair Series Connection
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 85 V
- Current - Average Rectified (Io) (per Diode): 140mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 1.1 V @ 50 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr): 3 µs
- Current - Reverse Leakage @ Vr: 5 nA @ 75 V
- Operating Temperature - Junction: -65°C ~ 150°C
- Mounting Type: Surface Mount
- Package / Case: 6-TSSOP, SC-88, SOT-363
- Supplier Device Package: SOT-363
