BAW56WT1
onsemi
onsemi
DIODE SWITCH DUAL CA 70V SOT323
$0.02
Available to order
Reference Price (USD)
1+
$0.02000
500+
$0.0198
1000+
$0.0196
1500+
$0.0194
2000+
$0.0192
2500+
$0.019
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Upgrade your circuitry with the BAW56WT1 by onsemi, a top-tier rectifier diode array from the Diodes - Rectifiers - Arrays subcategory. Engineered for precision and reliability, this component features fast switching and high current capacity, making it perfect for AC/DC conversion and voltage regulation. Common applications include welding machines, battery chargers, and renewable energy systems. With onsemi's commitment to quality, the BAW56WT1 stands out as a robust solution for engineers seeking optimal performance in harsh environments.
Specifications
- Product Status: Obsolete
- Diode Configuration: 1 Pair Common Anode
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 70 V
- Current - Average Rectified (Io) (per Diode): 200mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 150 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr): 6 ns
- Current - Reverse Leakage @ Vr: 2.5 µA @ 70 V
- Operating Temperature - Junction: -55°C ~ 150°C
- Mounting Type: Surface Mount
- Package / Case: SC-70, SOT-323
- Supplier Device Package: SC-70-3 (SOT323)
