CD54HCT02F
Harris Corporation
Harris Corporation
QUAD TWO-INPUT NOR GATE
$10.20
Available to order
Reference Price (USD)
1+
$10.20000
500+
$10.098
1000+
$9.996
1500+
$9.894
2000+
$9.792
2500+
$9.69
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The CD54HCT02F by Harris Corporation sets new standards in the Logic - Gates and Inverters category of Integrated Circuits. Featuring advanced silicon-gate CMOS technology, this IC delivers superior performance in logic level conversion and signal gating applications. Notable characteristics include symmetrical output drive capability, balanced propagation delays, and 3-state outputs for bus-oriented applications. Electronic designers frequently incorporate this component in data acquisition systems, test equipment, and digital displays. Practical applications range from factory automation to renewable energy systems and telecommunications infrastructure. The CD54HCT02F's EMC compliance ensures trouble-free integration into complex electronic systems.
Specifications
- Product Status: Active
- Logic Type: NOR Gate
- Number of Circuits: 4
- Number of Inputs: 2
- Features: -
- Voltage - Supply: 4.5V ~ 5.5V
- Current - Quiescent (Max): 2 µA
- Current - Output High, Low: 4mA, 4mA
- Logic Level - Low: 0.8V
- Logic Level - High: 2V
- Max Propagation Delay @ V, Max CL: 21ns @ 4.5V, 50pF
- Operating Temperature: -55°C ~ 125°C
- Mounting Type: Through Hole
- Supplier Device Package: 14-CDIP
- Package / Case: 14-CDIP (0.300", 7.62mm)
