CLL5230B BK TIN/LEAD
Central Semiconductor Corp
Central Semiconductor Corp
SURFACE MOUNT-DIODE-ZENER
$0.40
Available to order
Reference Price (USD)
1+
$0.40000
500+
$0.396
1000+
$0.392
1500+
$0.388
2000+
$0.384
2500+
$0.38
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The CLL5230B BK TIN/LEAD by Central Semiconductor Corp is a high-performance single Zener diode, part of the Discrete Semiconductor Products lineup. Designed for accuracy and reliability, this diode features low dynamic impedance and excellent temperature stability. It is widely used in voltage reference circuits, power supplies, and signal conditioning applications. For instance, the CLL5230B BK TIN/LEAD is essential in medical imaging devices, where it maintains precise voltage levels for accurate diagnostics. It also plays a critical role in aerospace electronics, ensuring reliable operation under extreme conditions. Furthermore, it is used in consumer electronics, such as smart TVs and home appliances, to enhance performance and longevity.
Specifications
- Product Status: Active
- Voltage - Zener (Nom) (Vz): 4.7 V
- Tolerance: ±5%
- Power - Max: 500 mW
- Impedance (Max) (Zzt): 19 Ohms
- Current - Reverse Leakage @ Vr: 5 µA @ 2 V
- Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 200 mA
- Operating Temperature: -65°C ~ 200°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: DO-213AC, MINI-MELF, SOD-80
- Supplier Device Package: SOD-80
