DD26M2S5WV5Z
Positronic
Positronic
CONN D-SUB HD PLUG 26P SLDR CUP
$48.22
Available to order
Reference Price (USD)
1+
$48.22000
500+
$47.7378
1000+
$47.2556
1500+
$46.7734
2000+
$46.2912
2500+
$45.809
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The DD26M2S5WV5Z D-Sub series by Positronic sets new benchmarks in the Connectors and Interconnects category. These high-density connectors pack up to 104 contacts in compact DA-26 shells while maintaining 500VAC isolation. Key applications include flight data recorders, nuclear power plant controls, and underground mining equipment where space efficiency and reliability are critical. The DD26M2S5WV5Z differentiates itself with integrated grounding lugs, removable contact modules, and optional potting for environmental sealing. Electrical engineers value these connectors for their low insertion force design and compatibility with automated assembly processes.
Specifications
- Product Status: Active
- Connector Style: D-Sub, High Density
- Connector Type: Plug, Male Pins
- Number of Positions: 26
- Number of Rows: 3
- Mounting Type: Free Hanging (In-Line)
- Shell Size, Connector Layout: 2 (DA, A) High Density
- Contact Type: Signal
- Flange Feature: Board Side (4-40)
- Termination: Solder Cup
- Primary Material: -
- Shell Material, Finish: Steel, Tin Plated
- Contact Finish: Gold
- Contact Finish Thickness: Flash
- Ingress Protection: IP65/IP67 - Dust Tight, Water Resistant, Waterproof
- Material Flammability Rating: UL94 V-0
- Current Rating (Amps): 5A
- Backset Spacing: -
- Features: Backshell, Cable Clamp, Mounting Hardware
