EC103E2AP
Littelfuse Inc.
Littelfuse Inc.
SCR 500V 800MA TO92
$0.00
Available to order
Reference Price (USD)
1+
$0.00000
500+
$0
1000+
$0
1500+
$0
2000+
$0
2500+
$0
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The EC103E2AP from Littelfuse Inc. redefines reliability in the Thyristors - SCRs category of Discrete Semiconductor Products. With its unique reverse blocking capability and high temperature operation range, this SCR is indispensable for power electronics. Typical uses include uninterruptible power supplies, induction heating, and plasma cutting machines. For example, it's essential in semiconductor manufacturing equipment. Littelfuse Inc.'s EC103E2AP combines advanced engineering with practical functionality.
Specifications
- Product Status: Obsolete
- Voltage - Off State: 500 V
- Voltage - Gate Trigger (Vgt) (Max): 800 mV
- Current - Gate Trigger (Igt) (Max): 50 µA
- Voltage - On State (Vtm) (Max): 1.7 V
- Current - On State (It (AV)) (Max): 510 mA
- Current - On State (It (RMS)) (Max): 800 mA
- Current - Hold (Ih) (Max): 5 mA
- Current - Off State (Max): 1 µA
- Current - Non Rep. Surge 50, 60Hz (Itsm): 16A, 20A
- SCR Type: Sensitive Gate
- Operating Temperature: -40°C ~ 110°C
- Mounting Type: Through Hole
- Package / Case: TO-226-3, TO-92-3 (TO-226AA) Formed Leads
- Supplier Device Package: TO-92
