FB3S025C11
JAE Electronics
JAE Electronics
CONN FPC BOTTOM 25POS 0.30MM R/A
$0.00
Available to order
Reference Price (USD)
1+
$0.00000
500+
$0
1000+
$0
1500+
$0
2000+
$0
2500+
$0
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The FB3S025C11 FFC/FPC Connectors by JAE Electronics deliver unparalleled reliability for mission-critical electronic systems. Designed with a dual-beam contact system, these connectors ensure low contact resistance and high mating stability even under mechanical stress. Applications range from underwater robotics to high-altitude aviation electronics, where the FB3S025C11's hermetic sealing options prove invaluable. JAE Electronics employs state-of-the-art SMT packaging for streamlined assembly processes. When failure is not an option, engineers worldwide trust FB3S025C11 connectors to maintain uninterrupted performance in extreme conditions.
Specifications
- Product Status: Obsolete
- Flat Flex Type: FPC
- Mounting Type: Surface Mount, Right Angle
- Connector/Contact Type: Contacts, Bottom
- Number of Positions: 25
- Pitch: 0.012" (0.30mm)
- Termination: Solder
- FFC, FCB Thickness: 0.20mm
- Height Above Board: 0.075" (1.90mm)
- Locking Feature: Flip Lock
- Cable End Type: Tapered
- Contact Material: Copper Alloy
- Contact Finish: Gold
- Housing Material: Liquid Crystal Polymer (LCP), Glass Filled
- Actuator Material: Polyamide (PA), Nylon, Glass Filled
- Features: Low Insertion Force (LIF)
- Voltage Rating: 50V
- Operating Temperature: -40°C ~ 85°C
- Material Flammability Rating: UL94 V-0
