FFAF05U120DNTU
Fairchild Semiconductor
Fairchild Semiconductor
RECTIFIER DIODE
$1.06
Available to order
Reference Price (USD)
1+
$1.06000
500+
$1.0494
1000+
$1.0388
1500+
$1.0282
2000+
$1.0176
2500+
$1.007
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The FFAF05U120DNTU rectifier array from Fairchild Semiconductor redefines efficiency in the Diodes - Rectifiers - Arrays classification. Its optimized chip geometry enables higher surge withstand capability, critical for automotive alternators and arc suppression circuits. This product shines in three-phase rectification and snubber networks, offering aerospace-grade reliability. Fairchild Semiconductor's precision manufacturing ensures each FFAF05U120DNTU meets stringent quality standards for mission-critical applications.
Specifications
- Product Status: Obsolete
- Diode Configuration: 1 Pair Common Cathode
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 1.2 V
- Current - Average Rectified (Io) (per Diode): 5A
- Voltage - Forward (Vf) (Max) @ If: 3.5 V @ 5 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 100 ns
- Current - Reverse Leakage @ Vr: 5 µA @ 1.2 V
- Operating Temperature - Junction: -65°C ~ 150°C
- Mounting Type: Through Hole
- Package / Case: TO-3P-3 Full Pack
- Supplier Device Package: TO-3PF
