IMP1-2Q1-1H1-1H1-1L1-1N1-1Q0-00-A

Specifications

• Product Status: Active
• Type: Enclosed
• Number of Outputs: 6
• Voltage - Input: 85 ~ 264 VAC, 120 ~ 300 VDC
• Voltage - Output 1: 24V
• Voltage - Output 2: 6V
• Voltage - Output 3: 6V
• Voltage - Output 4: 12V
• Voltage - Output 5: 15V
• Voltage - Output 6: 15V
• Current - Output 1: 15 A
• Current - Output 2: 23 A
• Current - Output 3: 23 A
• Current - Output 4: 17 A
• Current - Output 5: 14 A
• Current - Output 6: 8.5 A
• Power (Watts): 1500W
• Applications: ITE (Commercial), Medical
• Voltage - Isolation: 2 kV
• Efficiency: 85%
• Operating Temperature: -40°C ~ 70°C (With Derating)
• Features: Adjustable Output, I²C Interface, PFC, PMBus™, Remote Sense, Universal Input
• Mounting Type: Chassis Mount
• Size / Dimension: 11.00" L x 8.00" W x 2.50" H (279.4mm x 203.2mm x 63.5mm)
• Approval Agency: CB, CE, CSA, UL
• Standard Number: -
