IPD70N12S311ATMA1
Infineon Technologies
Infineon Technologies
MOSFET N-CH 120V 70A TO252-31
$2.29
Available to order
Reference Price (USD)
2,500+
$0.95604
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Upgrade your designs with the IPD70N12S311ATMA1 by Infineon Technologies, a top-tier single MOSFET in the Discrete Semiconductor Products range. This component shines in high-power applications such as server farms, electric vehicle charging stations, and smart grid technology. With its low conduction losses and high reliability, the IPD70N12S311ATMA1 is the ideal choice for engineers working with Transistors - FETs, MOSFETs - Single components.
Specifications
- Product Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 120 V
- Current - Continuous Drain (Id) @ 25°C: 70A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 10V
- Rds On (Max) @ Id, Vgs: 11.1mOhm @ 70A, 10V
- Vgs(th) (Max) @ Id: 4V @ 83µA
- Gate Charge (Qg) (Max) @ Vgs: 65 nC @ 10 V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 4355 pF @ 25 V
- FET Feature: -
- Power Dissipation (Max): 125W (Tc)
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: PG-TO252-3
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
