ISL8323IBZ-T
Intersil
Intersil
SPST, 2 FUNC, 1 CHANNEL, PDSO8
$2.71
Available to order
Reference Price (USD)
1+
$2.71000
500+
$2.6829
1000+
$2.6558
1500+
$2.6287
2000+
$2.6016
2500+
$2.5745
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Optimize your signal path design with Intersil's ISL8323IBZ-T, a flagship product in our Analog Switches and Multiplexers category. This IC combines low distortion (<0.01% THD) with high off-isolation (>80dB at 1MHz), making it ideal for high-fidelity applications. The breakthrough architecture enables simultaneous sampling across multiple channels while maintaining signal purity. Key implementations include: industrial process control interfaces, semiconductor test handlers, MRI machine front-ends, and 5G base station signal conditioning. The ISL8323IBZ-T meets stringent requirements for military-grade communications equipment and satellite payload management systems, offering radiation-hardened versions upon request.
Specifications
- Product Status: Active
- Switch Circuit: SPST - NO
- Multiplexer/Demultiplexer Circuit: 1:1
- Number of Circuits: 2
- On-State Resistance (Max): 60Ohm
- Channel-to-Channel Matching (ΔRon): 800mOhm
- Voltage - Supply, Single (V+): 2.7V ~ 12V
- Voltage - Supply, Dual (V±): 2.7V ~ 12V
- Switch Time (Ton, Toff) (Max): 150ns, 100ns
- -3db Bandwidth: -
- Charge Injection: 5pC (Max)
- Channel Capacitance (CS(off), CD(off)): 9pF, 9pF
- Current - Leakage (IS(off)) (Max): 100pA
- Crosstalk: -85dB @ 1MHz
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
