JAN1N4100D-1/TR
Microchip Technology
Microchip Technology
VOLTAGE REGULATOR
$12.78
Available to order
Reference Price (USD)
1+
$12.78000
500+
$12.6522
1000+
$12.5244
1500+
$12.3966
2000+
$12.2688
2500+
$12.141
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The JAN1N4100D-1/TR from Microchip Technology is a high-performance Zener diode designed for precision voltage regulation in various electronic circuits. As part of the Discrete Semiconductor Products category, this single Zener diode offers exceptional stability and reliability, making it ideal for applications requiring consistent voltage reference. Key features include low impedance, sharp breakdown characteristics, and excellent temperature stability. These diodes are widely used in power supplies, voltage clippers, and surge protectors. For instance, the JAN1N4100D-1/TR is commonly employed in automotive electronics, telecommunications equipment, and industrial control systems to ensure stable voltage levels and protect sensitive components from voltage spikes.
Specifications
- Product Status: Active
- Voltage - Zener (Nom) (Vz): 7.5 V
- Tolerance: ±1%
- Power - Max: -
- Impedance (Max) (Zzt): 200 Ohms
- Current - Reverse Leakage @ Vr: 1 µA @ 5.7 V
- Voltage - Forward (Vf) (Max) @ If: 1.1 V @ 200 mA
- Operating Temperature: -65°C ~ 175°C
- Mounting Type: Through Hole
- Package / Case: DO-204AH, DO-35, Axial
- Supplier Device Package: DO-35 (DO-204AH)
