JAN1N5545D-1/TR
Microchip Technology
Microchip Technology
VOLTAGE REGULATOR
$13.42
Available to order
Reference Price (USD)
1+
$13.42500
500+
$13.29075
1000+
$13.1565
1500+
$13.02225
2000+
$12.888
2500+
$12.75375
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover the JAN1N5545D-1/TR Zener diode by Microchip Technology, a standout in the Discrete Semiconductor Products lineup. This single Zener diode is engineered for precise voltage regulation, featuring a robust design that ensures long-term durability. With its low leakage current and high surge capability, the JAN1N5545D-1/TR is perfect for critical applications. Typical uses include voltage stabilization in consumer electronics, such as TVs and audio equipment, as well as in medical devices where consistent performance is paramount. The JAN1N5545D-1/TR is also a preferred choice for circuit protection in renewable energy systems, safeguarding inverters and charge controllers from voltage fluctuations.
Specifications
- Product Status: Active
- Voltage - Zener (Nom) (Vz): 30 V
- Tolerance: ±1%
- Power - Max: 500 mW
- Impedance (Max) (Zzt): 100 Ohms
- Current - Reverse Leakage @ Vr: 10 nA @ 27 V
- Voltage - Forward (Vf) (Max) @ If: 1.1 V @ 200 mA
- Operating Temperature: -65°C ~ 175°C
- Mounting Type: Through Hole
- Package / Case: DO-204AH, DO-35, Axial
- Supplier Device Package: DO-35 (DO-204AH)
