JANTX1N5542B-1/TR
Microchip Technology
Microchip Technology
VOLTAGE REGULATOR
$7.22
Available to order
Reference Price (USD)
1+
$7.21500
500+
$7.14285
1000+
$7.0707
1500+
$6.99855
2000+
$6.9264
2500+
$6.85425
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The JANTX1N5542B-1/TR Zener diode from Microchip Technology is a reliable component in the Discrete Semiconductor Products category. This single Zener diode offers precise voltage regulation, with features like low noise and high surge current capability. It is ideal for applications in power management, such as in DC-DC converters and voltage regulators. The JANTX1N5542B-1/TR is also used in automotive electronics, protecting sensitive components from voltage transients. Additionally, it is found in industrial automation systems, where it ensures stable operation of PLCs and robotic controls. Its versatility makes it a valuable asset in both consumer and industrial electronics.
Specifications
- Product Status: Active
- Voltage - Zener (Nom) (Vz): 22 V
- Tolerance: ±5%
- Power - Max: 500 mW
- Impedance (Max) (Zzt): 100 Ohms
- Current - Reverse Leakage @ Vr: 10 nA @ 19.8 V
- Voltage - Forward (Vf) (Max) @ If: 1.1 V @ 200 mA
- Operating Temperature: -65°C ~ 175°C
- Mounting Type: Through Hole
- Package / Case: DO-204AH, DO-35, Axial
- Supplier Device Package: DO-35 (DO-204AH)
