JANTX1N759A-1/TR
Microchip Technology
Microchip Technology
VOLTAGE REGULATOR
$2.41
Available to order
Reference Price (USD)
1+
$2.41498
500+
$2.3908302
1000+
$2.3666804
1500+
$2.3425306
2000+
$2.3183808
2500+
$2.294231
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The JANTX1N759A-1/TR by Microchip Technology is a high-performance single Zener diode, part of the Discrete Semiconductor Products lineup. Designed for accuracy and reliability, this diode features low dynamic impedance and excellent temperature stability. It is widely used in voltage reference circuits, power supplies, and signal conditioning applications. For instance, the JANTX1N759A-1/TR is essential in medical imaging devices, where it maintains precise voltage levels for accurate diagnostics. It also plays a critical role in aerospace electronics, ensuring reliable operation under extreme conditions. Furthermore, it is used in consumer electronics, such as smart TVs and home appliances, to enhance performance and longevity.
Specifications
- Product Status: Active
- Voltage - Zener (Nom) (Vz): 12 V
- Tolerance: ±5%
- Power - Max: 500 mW
- Impedance (Max) (Zzt): 10 Ohms
- Current - Reverse Leakage @ Vr: 1 µA @ 9 V
- Voltage - Forward (Vf) (Max) @ If: 1.1 V @ 200 mA
- Operating Temperature: -65°C ~ 175°C
- Mounting Type: Through Hole
- Package / Case: DO-204AH, DO-35, Axial
- Supplier Device Package: DO-35
