L7820CV
STMicroelectronics
STMicroelectronics
IC REG LINEAR 20V 1.5A TO220AB
$0.00
Available to order
Reference Price (USD)
4,000+
$0.20150
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover the L7820CV linear voltage regulator IC by STMicroelectronics, a standout product in our PMIC - Voltage Regulators - Linear category. This IC provides precise voltage regulation with ultra-low noise output, making it perfect for analog and RF circuits. The device features excellent PSRR (Power Supply Rejection Ratio) performance and comes in various package options to suit different design requirements. Linear regulators such as this L7820CV model are extensively used in consumer electronics (smartphones, tablets), IoT devices, and aerospace applications where consistent voltage without switching noise is essential. Its robust design ensures reliable operation in harsh environments with wide temperature ranges.
Specifications
- Product Status: Obsolete
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 40V
- Voltage - Output (Min/Fixed): 20V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 2V @ 1A (Typ)
- Current - Output: 1.5A
- Current - Quiescent (Iq): 8 mA
- Current - Supply (Max): -
- PSRR: 52dB (120Hz)
- Control Features: -
- Protection Features: Over Temperature, Short Circuit
- Operating Temperature: 0°C ~ 125°C
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220
