LM2940CSX-15

Texas Instruments

Manufacturer

Texas Instruments

Description:

IC REG LIN 15V 1A DDPAK/TO263-3

Datasheet:

LM2940CSX-15 Datasheet

$0.00

Available to order

Reference Price (USD)

500+

$1.16026

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

Optimize your power management with the LM2940CSX-15, a premium PMIC - Voltage Regulators - Linear IC from Texas Instruments. This IC delivers precise voltage regulation, ensuring optimal performance for your electronic circuits. With features like low dropout voltage, high output current, and excellent thermal stability, the LM2940CSX-15 is designed to excel in the most demanding applications. PMIC - Voltage Regulators - Linear ICs are vital for maintaining voltage integrity, and the LM2940CSX-15 is a prime example of this technology. It offers superior noise rejection and fast response times, making it ideal for sensitive applications. Its compact size and high efficiency also make it suitable for space-constrained designs. The LM2940CSX-15 is used in a variety of industries, including automotive, telecommunications, and industrial automation. For example, it is found in electric vehicle power systems, 5G infrastructure, and programmable logic controllers (PLCs). Its reliability and performance make it a trusted choice for engineers worldwide.

Specifications

Product Status: Obsolete
Output Configuration: Positive
Output Type: Fixed
Number of Regulators: 1
Voltage - Input (Max): 26V
Voltage - Output (Min/Fixed): 15V
Voltage - Output (Max): -
Voltage Dropout (Max): 0.8V @ 1A
Current - Output: 1A
Current - Quiescent (Iq): 10 mA
Current - Supply (Max): 15 mA
PSRR: 66dB (120Hz)
Control Features: -
Protection Features: Over Current, Over Temperature, Reverse Polarity, Short Circuit
Operating Temperature: 0°C ~ 125°C
Mounting Type: Surface Mount
Package / Case: TO-263-4, D²Pak (3 Leads + Tab), TO-263AA
Supplier Device Package: DDPAK/TO-263-3
