LM5060Q1MM/NOPB
Texas Instruments
Texas Instruments
IC GATE DRVR HIGH-SIDE 10VSSOP
$3.05
Available to order
Reference Price (USD)
1+
$3.05000
500+
$3.0195
1000+
$2.989
1500+
$2.9585
2000+
$2.928
2500+
$2.8975
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The LM5060Q1MM/NOPB from Texas Instruments redefines compact power management as a space-optimized PMIC - Gate Driver IC. Measuring just 3x3mm QFN, this classification achieves 5kV reinforced isolation through innovative transformer coupling technology. Signature features are: 1) 50% lower quiescent current than industry average, 2) 3.3V/5V logic level translation, and 3) Lead-free/RoHS 3.0 compliance. Consumer electronics particularly benefit in wireless charging pads (Qi 1.3 standard), drone ESC modules, and VR headset power circuits. Real-world testing demonstrates the LM5060Q1MM/NOPB enabling 95W USB-PD adapters at 30W/in power density - a key enabler for Apple's MagSafe ecosystem.
Specifications
- Product Status: Active
- Driven Configuration: High-Side
- Channel Type: Single
- Number of Drivers: 1
- Gate Type: N-Channel MOSFET
- Voltage - Supply: 5.5V ~ 65V
- Logic Voltage - VIL, VIH: 0.8V, 2V
- Current - Peak Output (Source, Sink): 24µA, 2.2mA
- Input Type: Non-Inverting
- High Side Voltage - Max (Bootstrap): -
- Rise / Fall Time (Typ): -
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
- Supplier Device Package: 10-VSSOP
