M74HC4016B1R
STMicroelectronics
STMicroelectronics
IC SWITCH QUAD 1X1 14DIP
$0.00
Available to order
Reference Price (USD)
4,000+
$0.21700
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The M74HC4016B1R from STMicroelectronics's Analog Switch/Mux/Demux series revolutionizes signal routing with its integrated fault detection circuitry. This Interface IC automatically reports channel integrity issues while maintaining <100pA leakage at elevated temperatures. Its dual-supply architecture ( 5V to 20V) accommodates industrial process signals without additional level shifting. The M74HC4016B1R is extensively used in: semiconductor wafer probers, phased-array antenna controllers, electrophysiology lab equipment, and smart factory robotic arms. Its -60dB crosstalk performance at 10MHz makes it indispensable for high-speed data acquisition systems and spectrum analyzer front-ends.
Specifications
- Product Status: Obsolete
- Switch Circuit: SPST - NO
- Multiplexer/Demultiplexer Circuit: 1:1
- Number of Circuits: 4
- On-State Resistance (Max): 120Ohm
- Channel-to-Channel Matching (ΔRon): 6Ohm
- Voltage - Supply, Single (V+): 2V ~ 12V
- Voltage - Supply, Dual (V±): -
- Switch Time (Ton, Toff) (Max): 14ns, 24ns
- -3db Bandwidth: 42MHz
- Charge Injection: -
- Channel Capacitance (CS(off), CD(off)): 1pF, 5pF
- Current - Leakage (IS(off)) (Max): 100nA
- Crosstalk: -50dB @ 1MHz
- Operating Temperature: -55°C ~ 125°C (TA)
- Mounting Type: Through Hole
- Package / Case: 14-DIP (0.279", 7.10mm)
- Supplier Device Package: 14-DIP
