M74HC4316TTR
STMicroelectronics
STMicroelectronics
IC SWITCH QUAD 1X1 16TSSOP
$0.00
Available to order
Reference Price (USD)
5,000+
$0.15805
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The M74HC4316TTR from STMicroelectronics's Analog Switch/Mux/Demux series revolutionizes signal routing with its integrated fault detection circuitry. This Interface IC automatically reports channel integrity issues while maintaining <100pA leakage at elevated temperatures. Its dual-supply architecture ( 5V to 20V) accommodates industrial process signals without additional level shifting. The M74HC4316TTR is extensively used in: semiconductor wafer probers, phased-array antenna controllers, electrophysiology lab equipment, and smart factory robotic arms. Its -60dB crosstalk performance at 10MHz makes it indispensable for high-speed data acquisition systems and spectrum analyzer front-ends.
Specifications
- Product Status: Obsolete
- Switch Circuit: SPDT
- Multiplexer/Demultiplexer Circuit: 2:1
- Number of Circuits: 4
- On-State Resistance (Max): 70Ohm
- Channel-to-Channel Matching (ΔRon): 5Ohm
- Voltage - Supply, Single (V+): 2V ~ 12V
- Voltage - Supply, Dual (V±): ±1V ~ 6V
- Switch Time (Ton, Toff) (Max): 18ns, 29ns
- -3db Bandwidth: 43MHz
- Charge Injection: -
- Channel Capacitance (CS(off), CD(off)): 1pF, 5pF
- Current - Leakage (IS(off)) (Max): 100nA
- Crosstalk: -50dB @ 1MHz
- Operating Temperature: -55°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package: 16-TSSOP
