MC74VHC1G135DT1G
onsemi
onsemi
IC GATE NAND 1CH 2IN 5TSOP
$0.05
Available to order
Reference Price (USD)
1+
$0.05000
500+
$0.0495
1000+
$0.049
1500+
$0.0485
2000+
$0.048
2500+
$0.0475
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The MC74VHC1G135DT1G by onsemi sets new standards in the Logic - Gates and Inverters category of Integrated Circuits. Featuring advanced silicon-gate CMOS technology, this IC delivers superior performance in logic level conversion and signal gating applications. Notable characteristics include symmetrical output drive capability, balanced propagation delays, and 3-state outputs for bus-oriented applications. Electronic designers frequently incorporate this component in data acquisition systems, test equipment, and digital displays. Practical applications range from factory automation to renewable energy systems and telecommunications infrastructure. The MC74VHC1G135DT1G's EMC compliance ensures trouble-free integration into complex electronic systems.
Specifications
- Product Status: Obsolete
- Logic Type: NAND Gate
- Number of Circuits: 1
- Number of Inputs: 2
- Features: Schmitt Trigger, Open Drain
- Voltage - Supply: 2V ~ 5.5V
- Current - Quiescent (Max): 1 µA
- Current - Output High, Low: -, 8mA
- Logic Level - Low: 0.65V ~ 1.45V
- Logic Level - High: 2.25V ~ 3.7V
- Max Propagation Delay @ V, Max CL: 9.7ns @ 5V, 50pF
- Operating Temperature: -55°C ~ 125°C
- Mounting Type: Surface Mount
- Supplier Device Package: 5-TSOP
- Package / Case: SOT-23-5 Thin, TSOT-23-5
