MMBD7000W_R1_00001
Panjit International Inc.
Panjit International Inc.
SURFACE MOUNT SWITCHING DIODE
$0.20
Available to order
Reference Price (USD)
1+
$0.20000
500+
$0.198
1000+
$0.196
1500+
$0.194
2000+
$0.192
2500+
$0.19
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The MMBD7000W_R1_00001 rectifier array from Panjit International Inc. redefines efficiency in the Diodes - Rectifiers - Arrays classification. Its optimized chip geometry enables higher surge withstand capability, critical for automotive alternators and arc suppression circuits. This product shines in three-phase rectification and snubber networks, offering aerospace-grade reliability. Panjit International Inc.'s precision manufacturing ensures each MMBD7000W_R1_00001 meets stringent quality standards for mission-critical applications.
Specifications
- Product Status: Active
- Diode Configuration: 1 Pair Series Connection
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 100 V
- Current - Average Rectified (Io) (per Diode): 200mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 1.1 V @ 100 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr): 4 ns
- Current - Reverse Leakage @ Vr: 3 µA @ 100 V
- Operating Temperature - Junction: -55°C ~ 150°C
- Mounting Type: Surface Mount
- Package / Case: SC-70, SOT-323
- Supplier Device Package: SOT-323
