MX34036UF2
JAE Electronics
JAE Electronics
CONN HEADER VERT 36POS 2.2MM
$3.26
Available to order
Reference Price (USD)
1+
$2.88000
10+
$2.76000
25+
$2.53000
50+
$2.41500
100+
$2.30000
250+
$2.01252
500+
$1.95500
1,000+
$1.66750
2,500+
$1.55250
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover the MX34036UF2 rectangular connector header from JAE Electronics, a top choice for male pin interconnections. These headers provide exceptional mechanical strength and electrical performance. With options for through-hole or surface mount, the MX34036UF2 adapts to different assembly processes. Ideal for use in automotive electronics, consumer gadgets, and IoT devices. JAE Electronics guarantees connectors that enhance your product's reliability and efficiency.
Specifications
- Product Status: Active
- Connector Type: Header
- Contact Type: Male Pin
- Pitch - Mating: 0.087" (2.20mm)
- Number of Positions: 36
- Number of Rows: 2
- Row Spacing - Mating: 0.118" (3.00mm)
- Number of Positions Loaded: All
- Style: Board to Cable/Wire
- Shrouding: Shrouded - 4 Wall
- Mounting Type: Through Hole
- Termination: Solder
- Fastening Type: Locking Ramp
- Contact Length - Mating: 0.303" (7.70mm)
- Contact Length - Post: 0.126" (3.20mm)
- Overall Contact Length: -
- Insulation Height: 0.925" (23.50mm)
- Contact Shape: Square
- Contact Finish - Mating: Tin
- Contact Finish Thickness - Mating: -
- Contact Finish - Post: Tin
- Contact Material: Brass
- Insulation Material: Syndiotactic Polystyrene (SPS), Glass Filled
- Features: Mounting Flange
- Operating Temperature: -40°C ~ 85°C
- Ingress Protection: -
- Material Flammability Rating: -
- Insulation Color: Gray
- Current Rating (Amps): 3A
- Voltage Rating: -
