NGB8206NSL3G
onsemi
onsemi
IGBT IGNITION 350V 20A D2PAK
$1.09
Available to order
Reference Price (USD)
1+
$1.09000
500+
$1.0791
1000+
$1.0682
1500+
$1.0573
2000+
$1.0464
2500+
$1.0355
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover the NGB8206NSL3G Single IGBT transistor by onsemi, a standout in the Discrete Semiconductor Products lineup. This component excels in high-voltage and high-current applications, featuring low conduction losses and excellent switching performance. Perfect for use in welding equipment, UPS systems, and induction heating, the NGB8206NSL3G ensures reliability and efficiency. Its rugged construction and advanced technology make it a top choice for engineers seeking durable and high-performing IGBTs. Upgrade your designs with the NGB8206NSL3G for unmatched power control.
Specifications
- Product Status: Obsolete
- IGBT Type: -
- Voltage - Collector Emitter Breakdown (Max): 390 V
- Current - Collector (Ic) (Max): 20 A
- Current - Collector Pulsed (Icm): -
- Vce(on) (Max) @ Vge, Ic: 1.9V @ 4.5V, 20A
- Power - Max: 150 W
- Switching Energy: -
- Input Type: Logic
- Gate Charge: -
- Td (on/off) @ 25°C: -
- Test Condition: -
- Reverse Recovery Time (trr): -
- Operating Temperature: -
- Mounting Type: Surface Mount
- Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Supplier Device Package: D²PAK
