NGTB10N60FG
onsemi
onsemi
IGBT 600V 10A TO220F3
$0.00
Available to order
Reference Price (USD)
1+
$2.04000
50+
$1.72460
100+
$1.46940
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The NGTB10N60FG Single IGBT transistor by onsemi is a high-performance component in the Discrete Semiconductor Products category. Featuring low switching losses and high reliability, it is perfect for demanding applications like medical imaging, defense systems, and data centers. The NGTB10N60FG ensures precise power control and long-term stability. With onsemi's reputation for excellence, this IGBT is a trusted choice for engineers worldwide. Incorporate NGTB10N60FG into your projects for superior results.
Specifications
- Product Status: Obsolete
- IGBT Type: -
- Voltage - Collector Emitter Breakdown (Max): 600 V
- Current - Collector (Ic) (Max): 20 A
- Current - Collector Pulsed (Icm): 72 A
- Vce(on) (Max) @ Vge, Ic: 1.7V @ 15V, 10A
- Power - Max: 40 W
- Switching Energy: -
- Input Type: Standard
- Gate Charge: 55 nC
- Td (on/off) @ 25°C: 40ns/145ns
- Test Condition: 300V, 10A, 30Ohm, 15V
- Reverse Recovery Time (trr): 70 ns
- Operating Temperature: 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-220-3 Full Pack
- Supplier Device Package: TO-220F-3FS
