NTS4101PT1G
onsemi
onsemi
MOSFET P-CH 20V 1.37A SC70-3
$0.46
Available to order
Reference Price (USD)
3,000+
$0.09833
6,000+
$0.09310
15,000+
$0.08526
30,000+
$0.08004
75,000+
$0.07220
150,000+
$0.07078
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The NTS4101PT1G from onsemi redefines excellence in the Transistors - FETs, MOSFETs - Single classification. This Discrete Semiconductor Product boasts advanced thermal management, high-frequency operation, and exceptional durability. Whether you're designing medical equipment, aerospace systems, or IoT devices, the NTS4101PT1G offers the precision and reliability you need. Trust onsemi to power your next breakthrough innovation.
Specifications
- Product Status: Active
- FET Type: P-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 20 V
- Current - Continuous Drain (Id) @ 25°C: 1.37A (Ta)
- Drive Voltage (Max Rds On, Min Rds On): 2.5V, 4.5V
- Rds On (Max) @ Id, Vgs: 120mOhm @ 1A, 4.5V
- Vgs(th) (Max) @ Id: 1.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 9 nC @ 4.5 V
- Vgs (Max): ±8V
- Input Capacitance (Ciss) (Max) @ Vds: 840 pF @ 20 V
- FET Feature: -
- Power Dissipation (Max): 329mW (Ta)
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: SC-70-3 (SOT323)
- Package / Case: SC-70, SOT-323
