PBC29DBAN

Sullins Connector Solutions

Manufacturer

Sullins Connector Solutions

Description:

CONN HEADER R/A 58POS 2.54MM

Datasheet:

PBC29DBAN Datasheet

$5.17

Available to order

Reference Price (USD)

$5.17000

10+

$4.96500

25+

$4.55120

50+

$4.34420

100+

$4.13730

250+

$3.62016

500+

$3.51674

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

Enhance your electronic assemblies with the PBC29DBAN rectangular connector header from Sullins Connector Solutions. These male pin connectors are built for high-performance applications, offering excellent signal integrity and durability. Suitable for use in automotive, medical, and telecommunications industries, the PBC29DBAN meets the highest industry standards. Sullins Connector Solutions provides connectors that ensure long-term reliability and performance.

Specifications

Product Status: Active
Connector Type: Header, Breakaway
Contact Type: Male Pin
Pitch - Mating: 0.100" (2.54mm)
Number of Positions: 58
Number of Rows: 2
Row Spacing - Mating: 0.100" (2.54mm)
Number of Positions Loaded: All
Style: Board to Board or Cable
Shrouding: Unshrouded
Mounting Type: Through Hole, Right Angle
Termination: Solder
Fastening Type: Push-Pull
Contact Length - Mating: 0.230" (5.84mm)
Contact Length - Post: 0.100" (2.54mm)
Overall Contact Length: -
Insulation Height: 0.240" (6.10mm)
Contact Shape: Square
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 10.0µin (0.25µm)
Contact Finish - Post: Tin
Contact Material: Phosphor Bronze
Insulation Material: Polybutylene Terephthalate (PBT)
Features: -
Operating Temperature: -65°C ~ 125°C
Ingress Protection: -
Material Flammability Rating: UL94 V-0
Insulation Color: Black
Current Rating (Amps): 3A
Voltage Rating: -
