PTF-110-01-S-D
Samtec Inc.
Samtec Inc.
2.00 MM PRESS-FIT SOCKET STRIP
$8.39
Available to order
Reference Price (USD)
1+
$8.39000
500+
$8.3061
1000+
$8.2222
1500+
$8.1383
2000+
$8.0544
2500+
$7.9705
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The PTF-110-01-S-D Samtec Inc. Rectangular Connectors - Headers, Receptacles, and Female Sockets offer superior connectivity solutions for modern electronics. Designed with versatility in mind, these connectors support high-speed data transfer and power delivery. Their compact design and rugged build make them suitable for aerospace, military, and IoT applications. Whether you need board-to-board, cable-to-board, or wire-to-wire connections, Samtec Inc. provides reliable options. Examples include avionics systems, defense equipment, and smart home devices.
Specifications
- Product Status: Active
- Connector Type: Socket
- Contact Type: Forked
- Style: Board to Board
- Number of Positions: 20
- Number of Positions Loaded: All
- Pitch - Mating: 0.079" (2.00mm)
- Number of Rows: 2
- Row Spacing - Mating: 0.079" (2.00mm)
- Mounting Type: Through Hole
- Termination: Press-Fit
- Fastening Type: Push-Pull
- Contact Finish - Mating: Gold
- Contact Finish Thickness - Mating: 3.00µin (0.076µm)
- Insulation Color: Black
- Insulation Height: 0.250" (6.35mm)
- Contact Length - Post: 0.090" (2.29mm)
- Operating Temperature: -55°C ~ 125°C
- Material Flammability Rating: -
- Contact Finish - Post: Tin
- Mated Stacking Heights: -
- Ingress Protection: -
- Features: -
- Current Rating (Amps): 2.9A per Contact
- Voltage Rating: -
