RD15S100T20
PEI-Genesis
PEI-Genesis
CONN D-SUB RCPT 15POS CRIMP
$23.69
Available to order
Reference Price (USD)
1+
$23.69000
500+
$23.4531
1000+
$23.2162
1500+
$22.9793
2000+
$22.7424
2500+
$22.5055
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The RD15S100T20 D-Sub series by PEI-Genesis sets new benchmarks in the Connectors and Interconnects category. These high-density connectors pack up to 104 contacts in compact DA-26 shells while maintaining 500VAC isolation. Key applications include flight data recorders, nuclear power plant controls, and underground mining equipment where space efficiency and reliability are critical. The RD15S100T20 differentiates itself with integrated grounding lugs, removable contact modules, and optional potting for environmental sealing. Electrical engineers value these connectors for their low insertion force design and compatibility with automated assembly processes.
Specifications
- Product Status: Active
- Connector Style: D-Sub
- Connector Type: Receptacle, Female Sockets
- Number of Positions: 15
- Number of Rows: 2
- Mounting Type: Free Hanging (In-Line)
- Shell Size, Connector Layout: 2 (DA, A)
- Contact Type: Signal
- Flange Feature: Mating Side, Female Screwlock (4-40)
- Termination: Crimp
- Primary Material: -
- Shell Material, Finish: Steel, Clear Chromate Plated Zinc
- Contact Finish: Gold
- Contact Finish Thickness: Flash
- Ingress Protection: IP65/IP67 - Dust Tight, Water Resistant, Waterproof
- Material Flammability Rating: UL94 V-0
- Current Rating (Amps): 7.5A
- Backset Spacing: -
- Features: -
